Diameter konduktor: |
Nganti 25mm |
Jembaré Sheave: |
75mm utawa 100mm |
Diameter jero saka Sheave: |
408 mm |
Diameter njaba saka Sheave: |
508 mm |
Packing: |
Wadah, Plywood... |
Bahan saka Sheave: |
Nilon utawa Aluminium Alloy |
Kabel Power Rollers Electric Single Wheel Kabel String Pulley Konduktor Stringing Blok
508MM Overhead Conductor Stringing Blocks (Mbukak metu pamblokiran) digunakake kanggo overhead transmisson line konduktor utawa OPGW stringing. The sheave saka pamblokiran digawe ing aluminium alloy diantrekake karo neoprene utawa kekuatan dhuwur MC Nylon.
508MM Overhead Transmission Line Kabel Stringing Blok
| Item No. | Model | Rentang Ukuran ACSR (mm²) | Beban Kerja (KN) | Bobot (kg) | Bahan saka Sheave |
| 10101 | SHD508 | 300-400 | 20 | 18 | Paduan aluminium |
| 10104 | SHDN508 | 300-400 | 20 | 16 | MC Nylon |
| 10104A | SHDN508X100 | 300-400 | 20 | 17 | MC Nylon |
| 10102 | SHS508 | 300-400 | 40 | 61 | baja Tengah utawa Nylon sheave, Side sheave Aluminium diantrekake karo neoprene |
| 10105 | SHSLN508 | 300-400 | 40 | 47 | |
| 10107 | SHSQN508 | 300-400 | 40 | 43 | Nilon, opsional bisa diantrekake karo neoprene |
| 10107A | SHSQN508X100 | 400 | 40 | 46 | |
| 10108 | SHWQN508 | 300-400 | 60 | 70 | |
| 10108A | SHWQN508X100 | 300-400 | 60 | 76 |
Aluminium sheave wis die casted karo stregnth dhuwur lan bobot entheng.
Aplikasi: Cocog kanggo senar tunggal, loro utawa telu, papat aluminium terdampar lan konduktor ACSR ing struktur tangen. Lengan kompresi, konektor putar, lan konektor tali tarik bisa ngliwati alur. Sheave digawe ing alloy aluminium utawa nilon kekuatan dhuwur. Sheave paduan aluminium ukuran 508X75 mm bisa dilapisi neoprene.
Cathetan:
1. Clevis fitting opsional, mangga nemtokake nalika pesenan. Blok sing disesuaikan bisa diwenehake kanthi panyuwunan. Data ing model tegese diameter njaba sheave X jembaré sheave (mm).
2. Kabeh sheaves sing dipasang ing bantalan werni. Pigura pamblokiran digawe saka baja galvanis.
