Istilah Perdagangan: |
FOB, CFR, CIF, DDP, CIP, EXW |
adat: |
Blok Stringing Konduktor Helikopter |
Sarana Transportasi: |
Samudra, Udara, Tanah |
Diameter konduktor: |
Nganti 25 Mm |
Big Diameter Nilon Single Sheave Kabel Stringing Pulley Wheel Acsr Konduktor Stringing Block
Single sheave Nylon Stringing Block
| Item No. | Model | Rentang Ukuran ACSR (mm²) | Beban Kerja (KN) | Bobot (kg) | Bahan saka Sheave |
| 10191 | SHDN-120x30 | 25-70 | 5 | 1.5 | Nylon |
| 10192 | SHDN-160x40 | 70-95 | 10 | 2.4 | |
| 10193 | SHDN-200x40 | 95-120 | 15 | 2.6 | |
| 10194 | SHDN-200x60 | 120-150 | 15 | 3.1 | |
| 10195 | SHDN-250x40 | 120-150 | 20 | 3.7 | |
| 10196 | SHDN-250x60 | 150-180 | 20 | 3.9 | |
| 10197 | SHDN-270x60 | 180-240 | 20 | 4.4 | |
| 10198 | SHDN-320x60 | 240-300 | 20 | 7.5 | |
| 10199 | SHDN-400x80 | 300-400 | 20 | 8 | |
| 10104 | SHDN508 | 300-400 | 20 | 16 | Nilon, opsional bisa diantrekake karo neoprene |
| 10124 | SHDN660 | 400-500 | 20 | 24 | |
| 10131 | SHDN750 | 500-600 | 30 | 32 | |
| 10141 | SHDN822 | 600-700 | 30 | 38 | |
| 10151 | SHDN916 | 700-800 | 50 | 51 | |
| 10165 | SHDN1040 | 800-900 | 50 | 60 |
Aplikasi: Cocog kanggo senar aluminium terdampar lan konduktor ACSR ing struktur tangen. Lengan kompresi, konektor putar, lan konektor tali tarik bisa ngliwati alur.
