NAMA: |
ALUMINIUM PULLEY BLOCK |
ITEM: |
PENGANGKATAN TACKLE |
RATE LOAD: |
2TON |
BAHAN: |
ALUMINIUM GEDUNG |
APLIKASI: |
FOR ERECT THE ROWER |
BOOT: |
2,9kg |
2 Ton Aluminium Sheave Hositing Tackle Transmisi Line Stringing Aluminium Pulley Block
Produk Hoisting Tackle (Aluminium sheave):
|
nomer item |
Model |
Jumlah sheaves |
Rated load (kN) |
(MM) Roller Diaxwidth |
(mm) MAX. Diameter tali |
Bobot (kg) |
| 11301 | QHL1x1 | 1 | 10 | Φ100×31 | F8 | 2 |
| 11302 | QHL1x2 | 2 | Φ80×27 | F6 | 2 | |
| 11303 | QHL1x3 | 3 | Φ80×27 | F6 | 2 | |
| 11311 | QHL2x1 | 1 | 20 | Φ120×35 | Φ10 | 3 |
| 11312 | QHL2x2 | 2 | Φ100×31 | F8 | 3 | |
| 11313 | QHL2x3 | 3 | Φ100×31 | F8 | 4 | |
| 11321 | QHL3x1 | 1 | 30 | Φ150×39 | F11 | 4 |
| 11322 | QHL3x2 | 2 | Φ120×35 | Φ10 | 4 | |
| 11323 | QHL3x3 | 3 | Φ100×31 | F8 | 5 | |
| 11331 | QHL5x1 | 1 | 50 | Φ166×40 | F13 | 6 |
| 11332 | QHL5x2 | 2 | Φ150×39 | F11 | 6 | |
| 11333 | QHL5x3 | 3 | Φ120×35 | Φ10 | 7 | |
| 11341 | QHL8x1 | 1 | 80 | Φ205×49 | F18 | 9 |
| 11342 | QHL8x2 | 2 | Φ166×40 | F13 | 9 | |
| 11343 | QHL8x3 | 3 | Φ150×39 | F11 | 10 | |
| 11351 | QHL10x1 | 1 | 100 | Φ246×60 | Φ20 | 12 |
| 11352 | QHL10x2 | 2 | Φ166×40 | F13 | 12 | |
| 11353 | QHL10x3 | 3 | Φ150×39 | F11 | 13 |
Informasi cepet:
1. Lingkaran merek
2. Hoisting nyegat karo Aluminium sheave
3. Rated load punika 20KN
Konfigurasi tackle angkat roda aluminium:
Panganggo: Aplikasi kanggo ngumpul lan ngadegake menara, konstruksi baris, piranti kerekan lan operasi kerekan liyane.
Fitur:Produk digawe saka piring paduan aluminium kanthi roda alloy aluminium, bobote entheng.
Spesifikasi: Gaya aksesoris kudu dituduhake kayata jinis mbukak, jinis tutup, jinis pancing lan jinis dering nalika pesenan pelanggan.
